Grout and Joints: What to Specify

Grout is chosen last, in a hurry, at the end of a long project — and it is the thing most often blamed two years later. It deserves ten minutes of proper thought.

Monochrome checkerboard floor tile showing fine grout joints

Clients spend months choosing a tile and about ninety seconds choosing what goes between the tiles. Yet the joint is roughly what you see when you look down a floor at a shallow angle, it is the part that stains, and it is the part that fails first if it is wrong for the room. The good news is that there are only four decisions — width, material, colour and movement — and each one has a fairly clear answer once the room is known.

Joint width, and why it is not zero

Rectified tiles — machine-edged after firing so every piece is dimensionally identical — allow joints of 2–3 mm, and that is what gives large formats their continuous look. Non-rectified tiles vary slightly piece to piece and need a wider joint, typically 3–5 mm, to absorb the variation.

No tiled surface should be laid without a joint. The joint absorbs thermal movement, minor structural movement and the dimensional tolerance of the tile itself. Butt-jointed tiling looks impressive for one season and then chips along its edges, because two hard surfaces with nowhere to move take the stress at their corners. A fine joint is a working detail, not a compromise.

Cementitious or epoxy

Cementitious grout is the default: workable, repairable, available in a wide colour range and entirely adequate for dry-area floors and walls. Its weakness is porosity — it absorbs water and staining, and in a shower or a kitchen splash zone it will discolour over time even when sealed.

Epoxy grout is non-porous, chemically resistant and effectively stain-proof, which makes it the right choice for showers, wet rooms, kitchen backsplashes, terraces and pool surrounds. It costs more to install because it demands a faster, more disciplined application — it must be cleaned off the tile face within its working window or it sets on the surface. Insist on a team that has used it before, and specify it room by room rather than across the whole house.

Colour: match or contrast, decide deliberately

Matching the grout to the tile makes the surface read as continuous and lets the material dominate — the usual choice for large-format floors and slab walls, where the entire point is to minimise the grid. Contrasting grout does the opposite: it draws the eye to the pattern, which is what a hexagon, an encaustic-look or a subway layout is often for.

Two practical notes. Avoid brilliant white on floors — it is the least forgiving colour there is, and it shows every mark within a year; a soft grey or a warm off-white does the same visual job and ages far better. And in wet areas, choose a mid-tone rather than either extreme, since both very light and very dark grouts show water marks and residue most clearly.

Movement joints — the detail everyone omits

A tiled floor expands and contracts. It needs a soft, flexible joint wherever it meets a wall, at internal corners, over structural joints, around columns, and at intervals across a large field — commonly in the region of every 6 to 8 metres indoors, and considerably closer outdoors where temperature swing is greater.

These are filled with a flexible sealant, not grout, and they are usually hidden under the skirting at the perimeter so nothing is visible. Omitting them is the single most common cause of tiles tenting or debonding in a large floor a year or two after laying — a failure that has nothing to do with the tile or the adhesive. Punjab's summer-to-winter swing makes this worth insisting on, especially on terraces and balconies.

Getting it specified on your project

Bring the tile selection and the room list to the studio and we will set out the joint width, grout type and colour room by room, and mark where movement joints belong — a fifteen-minute exercise at Sector 82, Mohali that saves a repair later. Our tiles page covers surface and slip choices for wet areas, and the large-format guide covers the substrate work that sits underneath all of it.

The IDC Library

More guides to keep reading

Open living space finished in large-format stone-look porcelain
Tiles · 6 min read

Large-Format Tiles and Slabs, Explained

What actually changes past 800x1600 mm — substrate flatness, adhesive, handling, layout and edge detail, and how to brief an installer for it.

Read the guide →
Poolside terrace paved in textured outdoor porcelain
Safety · 5 min read

Slip Resistance in Tiles, Explained

R ratings, barefoot classes and DCOF in plain language — and which surface belongs on a bathroom floor, a terrace and a poolside.

Read the guide →

All Guides

Questions We Are Asked Often

Questions about this guide

What grout joint width should I use?

For rectified tiles, 2–3 mm — this is what gives large formats their near-seamless look. For non-rectified tiles, typically 3–5 mm to absorb the dimensional variation between pieces. No tiled surface should be laid butt-jointed: the joint absorbs movement and tolerance, and without it the tile edges chip.

Should I use epoxy or cementitious grout?

Use epoxy in showers, wet rooms, kitchen backsplashes, terraces and pool surrounds — it is non-porous and effectively stain-proof. Cementitious grout is perfectly adequate for dry-area floors and walls, and is easier to apply and repair. Specify it room by room rather than choosing one for the whole house.

Is epoxy grout difficult to install?

It is less forgiving than cementitious grout. It sets faster and must be cleaned from the tile face within its working window, or it hardens on the surface and becomes very difficult to remove. It is entirely routine for a team that uses it regularly — the thing to confirm is that your team does.

What grout colour should I choose?

Match the grout to the tile when you want the surface to read as continuous, which is usually right for large-format floors and slab walls. Contrast it when the pattern is the point, as with hexagons, encaustic looks or subway layouts. Avoid brilliant white on floors; a soft grey or warm off-white looks similar and ages far better.

What is a movement joint and do I need one?

A movement joint is a flexible, sealant-filled gap that lets a tiled floor expand and contract. They belong at perimeters, internal corners, over structural joints, around columns and at intervals across large floors — commonly every 6 to 8 metres indoors and closer outdoors. Omitting them is a leading cause of tiles tenting or debonding a year or two after laying.

Why is my grout discolouring?

Cementitious grout is porous, so in wet or greasy areas it absorbs water and staining and darkens over time even when sealed. In those rooms the durable answer is epoxy grout rather than resealing. On floors, very white grout also simply shows normal traffic soiling faster than a mid-tone would.

Can I change the grout colour later without replacing the tiles?

Existing grout can be raked out and replaced, which is disruptive and rarely as clean as getting it right the first time, particularly with fine 2–3 mm joints on large-format tiles. It is far easier to decide the colour at specification stage against the actual tile in daylight.
